Embedded Artists iMX RT1062 - SP17: M.2 (NGFF) E-Key Connector; Default Jumpers Positions

iMX RT1062 OEM Developer’s Kit - User’s Guide
Page 33
Copyright 2019 © Embedded Artists AB
The M.2 audio interface typically comes from a Bluetooth interface. With the help of the multiplexors,
the audio data can be directed to the i.MX RT or the audio codec.
4.15.4 SP17: M.2 (NGFF) E-key Connector
This page contains the actual M.2 connector, J38. There are also four debug interface connectors.
These are normally not used, but can be when debugging difficult problems. Note that the debug
interfaces are specific for each M.2 module.
4.16 Default Jumpers Positions
Figure 27 illustrates the default jumper positions as mounted when the board is delivered from
Embedded Artists. Default jumpers are marked with red color.
Figure 27 – iMX OEM Base Board Default Jumper Positions
