iMX RT1062 OEM Developer’s Kit - User’s Guide
Copyright 2019 © Embedded Artists AB
There is also jumper to allow a specific signal (GPIO_B1_13) to control the watchdog input signal,
WDOG_B. This jumper is inserted by default.
Figure 18 –Location of Watchdog Control Jumper, J9
Watchdog Control
J9 inserted by default
