GPIO_B0_10-BOOT_CFG1[6]-
LCDIF_D6
GPIO_B0_10
Parallel RGB LCD interface - Green3 bit
GPIO_B0_11-BOOT_CFG1[7]-
LCDIF_D7
GPIO_B0_11
Parallel RGB LCD interface - Green4 bit
GPIO_B0_12-BOOT_CFG2[0]-
LCDIF_D8
GPIO_B0_12
Parallel RGB LCD interface - Green5 bit
GPIO_B0_13-BOOT_CFG2[1]-
LCDIF_D9
GPIO_B0_13
Parallel RGB LCD interface - Green6 bit
GPIO_B0_14-BOOT_CFG2[2]-
LCDIF_D10
GPIO_B0_14
Parallel RGB LCD interface - Green7 bit
GPIO_B0_05-BOOT_CFG1[1]-
LCDIF_D1
GPIO_B0_05
Parallel RGB LCD interface - Blue4 bit
GPIO_B0_06-BOOT_CFG1[2]-
LCDIF_D2
GPIO_B0_06
Parallel RGB LCD interface - Blue5 bit
GPIO_B0_07-BOOT_CFG1[3]-
LCDIF_D3
GPIO_B0_07
Parallel RGB LCD interface - Blue6 bit
GPIO_B0_08-BOOT_CFG1[4]-
LCDIF_D4
GPIO_B0_08
Parallel RGB LCD interface - Blue7 bit
GPIO_AD_B1_14-
SAI1_TX_BCLK
GPIO_AD_B1_14
Connects to audio codec: TX_BCLK
GPIO_AD_B1_13-SAI1_TXD
GPIO_AD_B1_13
Connects to audio codec: TX_DATA
GPIO_AD_B1_15-
SAI1_TX_SYNC
GPIO_AD_B1_15
Connects to audio codec: TX_SYNC
GPIO_SD_B1_04-
FLEXSPI_CLK_B
GPIO_SD_B1_04
No special usage on iMX OEM Carrier Board.
GPIO_AD_B1_12-SAI1_RXD
GPIO_AD_B1_12
Connects to audio codec: RX_DATA
POR_B
POR_B
No special usage on iMX OEM Carrier Board. Can
optionally be controlled by SW3 if JP8 is in 2-3 pos.
ONOFF
ONOFF
Connects to push-button SW2
OTG1_CHD
OTG1_CHD
No special usage on iMX OEM Carrier Board.
WAKEUP
WAKEUP
Connects to push-button SW4
GPIO_AD_B1_09-SAI1_MCLK
GPIO_AD_B1_09
Connects to audio codec: MCLK
PMIC_ON_REQ
PMIC_ON_REQ +
Reset generator
No special usage on iMX OEM Carrier Board.
EXT_PWR_EN
PMIC_REQ_ON
Enables the main 3.3V power supply.
PERI_PWREN
PMIC_STBY_REQ
Enables the 3.3V peripheral voltage supply.
GPIO_B1_13-WDOG_B
GPIO_B1_13
Is connected to WDOG_B input via J9.
GPIO_AD_B1_02
GPIO_AD_B1_02
Connects to M.2 interface as BT_HOST_WAKE.
Can be disconnected via J33, 3-4 position.
GPIO_AD_B1_03
GPIO_AD_B1_03
Connects to M.2 interface as WL_HOST_WAKE.
Can be disconnected via J33, 1-2 position.
