Introduction
SD32+
System
ports
Headbox Connection Port – This port connects the Headbox directly to the amplifier when the
Headbox is “docked”.
Patient Box Link Port – This port connects the Headbox to the amplifier when using the
Headbox to Amplifier Cable.
Note: When the Patient Box Link port is not in use replace the plastic cover provided to
prevent dust build up on this connector.
Optical Link Port – This port connects the amplifier to the Sandman elink Adapter using a fiber
optic cable.
Pulse Oximetry Sensor Port – This port accepts signals from an external finger probe and sends
them to the internal pulse oximeter.
Warning: Always use sensors that have been approved by Embla Systems. Sensors must also
be cleared for commercial use in your jurisdiction. The oximeter does not possess
alarm management capabilities and is not intended for continuous patient
monitoring.
Serial I/O Port – This port is reserved for future development.
sockets
DC In Socket – This socket accepts the 15V direct current (DC) voltage from the AC/DC
Adapter.
Warning: The DC In socket is only designed for use with the External Medical Grade
AC/DC Adapter provided with the SD32+ amplifier. Do not connect anything else
to this socket.
Isolated Aux I/O – This socket is reserved for future development.
Warning: Do not connect any device to the Isolated Aux I/O socket that has not been
specified as safe by Embla Systems. Such an action may compromise the safety of
the operator and/or patient.
