SD32+ System Specifications
8.7. Sandman
®
elink ™ adapter
Part Number 4200036
Case Materials: ABS plastic
Dimensions: 137 x 200 x 8 mm
Weight: 0.2 Kg
Power supply AULT SW173 or SINPRO MPU50-106
Interfaces: HP 100 Mb fiber-optic Transmitter and Receiver
RJ45 for Ethernet 100 bT Network link.
Triad F/M 4+1 per external power supply SW173
MCH Triad - HiRose HR12-10R-8SDL connector for RS232,
Trigger I/O, power supply
QM10-8R-PR HiRose connector for analogical output of digital signals.
Status indicators: Green LED: 3.3 V power is on.
* Yellow LED: Ethernet. Auto-negotiation controller.
# Yellow LED: Ethernet. Link 10 /100 Mb controller.
o Yellow LED: Ethernet. LAN controller.
Device rated values CE0051 mark (93/42/EEC)
cCSAus mark
8.8. DC expansion box specifications
8.8.1. technical characteristics
Part Number 4200024
Supply 5V (± 5%) / 0.5 A max
Case Plastic
Dimension 115 x 70 x 45 mm (L x W x H)
Weight 250 g
Inputs 8 x 1/8th inch male mono inputs
Maximum Channel Frequency 64 Hz
Connection to Computer Serial or USB
Number of Analog Inputs 8
Analog Input Signal Range ±5 V ( DC to 16 Hz )
Sampling Rate 8, 16, 32, 64 samples/second – host selectable
Input Impedance > 100 kOhms
A/D Conversion 12 bits
