SD32+
System Specifications
8.4.4. sampling rate
max sampling rate
Number of Simultaneously Acquired
Channels Maximum Sampling Rate
1 to 16 32768 Hz
16 to 32 16384 Hz
32 to 40 8192 Hz
Selectable Sampling Rate 128,256,512… 32768 Hz (according to the limit of the
maximum sampling rate)
sampling skew
All acquired channels will be sampled simultaneously (no sampling skew)
CMRR >100 dB (>95 dB on polygraphic channels)
IMRR >120 dB
Max. DC Offset (AC Mode)
± 300 mV
8.5. headbox specifications
Part Number 4200017
Case ABS Plastic
Dimension 126 x 96 x 25 mm
Electrode Connectors 32 active – one active connection to each input
(monopolar)
16 active – two active connections to each input (bipolar)
3 for neutral electrode
13 for isolated ground electrode
2 for temperature probe input
2 for calibration signal output
Connection to Amplifier Extension
Cable
50 pin Microcentronics male
Shielded cable (max 2m)
33
