ES120 OPERATION MANUAL
IU ES120 2009-03-01 ENG.3.0
7. Preparation of the system for work
The system is prepared for work by connecting the power lead and accessories.
The
supply cable
can only be plugged or unplugged when the generator is off. The generator
is made in accordance with the 1
st
class of fire-hazard protection, and so it requires a
grounding pin in the power supply socket. The power supply socket is located on the backside
of the casing
(Fig. 4, pos. 8)
.
The generator does not require any additional grounding pins
(Fig. 4, pos. 6)
. It is used for
grounding if a socket without grounding is used or in places where the fire protection system
requires it.
The foot switch is connected to socked
5
in the back side of the encasing
(Fig.4)
.
The connection mode of the accessories is explain in
Fig. 5
.
The neutral electrode is not needed for performing bipolar procedures. More information
about the neutral electrode can be found in Section: “8.2. Neutral electrode control ”
Power settings.
Prior to an operation power should be set. It is set independently for operations of cutting and
coagulation. The maximum wattage is indicated on displays assigned to each type of
operation. The settings are changed by arrow-signed keys.
Before the first use of the system it is well-advised to become familiar
with the effects of different settings by performing tests on fresh beef.
