If any number, other than 0 is programmed into this parameter the user security is applied so that no parameters except Pr 11.44 can be adjusted with
the LED keypad. When this parameter is read via an LED keypad and security is locked it appears as zero. The security code can be modified via
serial comms etc. by setting this parameter to the required value, setting Pr 11.44 to 3 and initiating a reset by setting Pr 10.38 to 100. However
security can only be cleared via the LED keypad.
This parameter indicates the continuous industrial current rating of the drive for heavy-duty operation. If this parameter is programmed into the level
two area, the decimal place on the drives four digit display will be adjusted to 1 for drive sizes with current ratings greater than 99.99A.
This parameter has four possible values and indicates the output voltage rating of the drive.
0: 200 200V product
1: 400 400V product
2: 575 575V product
3: 690 690V product
See Pr 11.29 on page 146.
This parameter indicates the version of DSP software installed.
11.30 User security code {25}
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 1111
Range 0 to 999
Default 0
Update rate Background
11.31 Unused parameter
11.32 Maximum heavy duty drive current rating
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1 1
Range 0.00 to 290.00 A
Update rate N/A
11.33 Drive voltage rating
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11111
Range 200(0), 400(1), 575(2), 690(3)
Update rate N/A
11.34 Software sub-version
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 0 to 99
Update rate N/A
11.35 DSP software version
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1 1
Range 0.0 to 9.9
Update rate N/A
11.36 to 11.40 Unused parameters
