10.18 Menu 21: Second motor map
Table 10-31 Menu 21 parameters: single line descriptions
Parameter Range Default Setting Update Rate
21.01 Motor 2 maximum set speed 0.0 to 550 Hz 50(Eur), 60(USA)
B
21.02 Motor 2 minimum set speed 0.0 to Pr 21.01 0.0
B
21.03 Motor 2 reference selector
A1.A2(0), A1.Pr(1), A2.Pr(2),
Pr(3), PAd(4), Prc(5)
A1.A2(0)
5 ms
21.04 Motor 2 acceleration rate 0.0 to 3200.0 s/100 Hz 5.0
5 ms
21.05 Motor 2 deceleration rate 0.0 to 3200.0 s/100 Hz 10.0
5 ms
21.06 Motor 2 motor rated frequency 0.0 to 550 Hz 50.0(Eur), 60.0(USA)
B
21.07 Motor 2 motor rated current
0 to RATED_
CURRENT_MAX A
Drive rated current
{Pr 11.32}
B
21.08 Motor 2 motor rated full load rpm 0 to 9999 rpm 1500(Eur), 1800(USA)
B
21.09 Motor 2 motor rated voltage
0 to AC_VOLTAGE_SET_
MAX V
110V drive: 230
200V drive: 230
400V drive: 400(Eur)
460(USA)
575V drive: 575
690V drive: 690
128 ms
21.10 Motor 2 motor rated power factor 0.00 to 1.00 0.85
B
21.11 Motor 2 number of motor poles
Auto(0), 2P(1), 4P(2), 6P(3),
8P(4)
Auto(0)
B
21.12 Motor 2 stator resistance 0.000 to 65.000 Ω 0.00
B
21.13 Motor 2 voltage offset 0.0 to 25.0 V 0.0
B
21.14
Motor 2 transient inductance (σL
s
)
0.00 to 320.00 mH 0.00
B
21.15 Motor 2 active OFF(0) to On(1) OFF(0)
B
21.16 Motor 2 thermal time constant 0 to 250 89
B
21.17 Not used
21.18 Not used
21.19 Not used
21.20 Not used
21.21 Not used
21.22 Not used
21.23 Not used
21.24 Not used
21.25 Not used
21.26 Not used
21.27 Not used
21.28 Not used
21.29 Motor 2 symmetrical current limit
0 to
MOTOR2_CURRENT_LIMIT_
MAX%
165.0 B
