Emerson Copeland Scroll XFAM Series User Manual

31
AE5-1412 R1
© 2016 Emerson Climate Technologies, Inc.
12. Sensor Values
°F
Resistance
(kOhms)
-40 2889.60
-31 2087.22
-22 1522.20
-13 1121.44
-4 834.72
5 627.28
14 475.74
23 363.99
32 280.82
41 218.41
50 171.17
59 135.14
68 107.44
77 86.00
86 69.28
95 56.16
104 45.81
113 37.58
122 30.99
131 25.68
140 21.40
149 17.91
158 15.07
167 12.73
176 10.79
185 9.20
194 7.87
203 6.77
212 5.85
221 5.09
230 4.45
239 3.87
248 3.35
257 2.92
266 2.58
275 2.28
284 2.02
293 1.80
302 1.59
311 1.39
320 1.25
329 1.12
338 1.01
347 0.92
356 0.83
°F
Resistance
(kOhms)
-55 302.2
-50 254.9
-45 221.7
-40 188.5
-35 160.2
-30 140.4
-25 120.2
-20 105.7
-15 90.8
-10 80.3
-5 69.4
0 61.5
5 53.4
10 46.5
15 41.5
20 36.3
25 32.4
30 28.5
35 25.6
40 22.5
45 20.3
50 18.0
55 15.9
60 14.4
65 12.8
70 11.6
75 10.4
80 9.46
85 8.47
°F
Resistance
(kOhms)
90 7.73
95 6.94
100 6.25
105 5.73
110 5.17
115 4.75
120 4.30
125 3.96
130 3.59
135 3.32
140 3.02
145 2.75
150 2.55
155 2.33
160 2.16
165 1.98
170 1.84
175 1.69
180 1.58
185 1.45
190 1.34
195 1.25
200 1.15
205 1.08
210 0.998
215 0.937
220 0.868
225 0.816
230 0.758
Discharge Line
Temperature Sensor Resistance
Temperature Sensor Resistance
(Excludes DLT)
