Table 9-128 Virtual parameter reference
Table 9-129 EtherCAT interface parameter reference
Parameter Default Description Cross reference
Pr 61.01 0 Parameter 1.00 shortcut Section 9.24.4 on page 95
Pr 61.03 1 Drive synchronization control Section 9.24.5 on page 95
Pr 61.04 1 Inter-option module synchronization control Section 9.24.6 on page 95
Pr 61.05 0 Inter-option clock synchronization control Section 9.24.7 on page 95
Pr 61.07 0 Option slot indicator Section 9.24.8 on page 96
Pr 61.40 0 Option hardware issue Section 9.24.9 on page 96
Pr 61.42 0 500 ms Task % free Section 9.24.10 on page 96
Pr 61.43 0 External memory % free Section 9.24.11 on page 96
Pr 61.44 0 Internal memory % free Section 9.24.12 on page 96
Pr 61.49 0 The EtherCAT interface error sub-code Section 9.24.13 on page 96
Pr 61.50 0 Bootloader software version - major and minor (XX.YY) Section 9.24.14 on page 96
Pr 61.51 0 Bootloader software version -subversion (ZZ) Section 9.24.15 on page 96
Object Description Default Range Cross reference
Pr 17.01 EtherCAT interface ID code 421 - - - - Section 14.4.1 on page 199
Pr 17.02 EtherCAT interface firmware - major and minor version N/A 00.00 to 99.99 Section 14.4.2 on page 199
Pr 17.03 Node address 0 0 to 65535 Section 9.11 on page 75
Pr 17.04 EtherCAT interface RUN 1 1 to 8 Section 9.12 on page 75
Pr 17.06 EtherCAT interface operating status N/A -9999 to 9999 Section 14.6 on page 200
Pr 17.10
EoE - IP address W
ip
0 0 to 255
Table 9-30 on page 80
Pr 17.11
EoE - IP address X
ip
Table 9-31 on page 80
Pr 17.12
EoE - IP address Y
ip
Table 9-32 on page 80
Pr 17.13
EoE - IP address Z
ip
Table 9-33 on page 80
Pr 17.14
EoE - Subnet mask W
subnet
Table 9-34 on page 80
Pr 17.15
EoE - Subnet mask X
subnet
Table 9-35 on page 80
Pr 17.16
EoE - Subnet mask Y
subnet
Table 9-36 on page 80
Pr 17.17
EoE - Subnet mask Z
subnet
Table 9-37 on page 80
Pr 17.18
EoE - Default gateway W
gateway
Table 9-38 on page 81
Pr 17.19
EoE - Default gateway X
gateway
Table 9-39 on page 81
Pr 17.20
EoE - Default gateway Y
gateway
Table 9-40 on page 81
Pr 17.21
EoE - Default gateway Z
gateway
Table 9-41 on page 81
Pr 17.32 EtherCAT interface re-initialize 0 (OFF) 0 (OFF) to 1 (ON) Section 9.12 on page 75
Pr 17.35 EtherCAT interface serial number N/A 0 to 16777215 Section 14.9 on page 201
Pr 17.37 Reduce Drive serial interface priority OFF OFF - ON Section 9.17.4 on page 81
Pr 17.44 EtherCAT interface temperature N/A 0 to 255 Section 14.8 on page 201
Pr 17.46 Critical task % free N/A 0 to 100
Section 14.12 on page 203
Pr 17.47 Worst case critical task % free N/A 0 to 100
Pr 17.48 Flash file system % free N/A 0 to 100 Section 14.14 on page 203
Pr 17.50 EtherCAT interface error code N/A 0 to 255 Section 14.10 on page 201
Pr 17.51 EtherCAT interface firmware - subversion N/A 0 to 99 Section 14.4.2 on page 199
