132 Digitax ST User Guide
Issue Number: 5
Parameter
Range(
Ú)Default(Ö)
Type
5.01 Output frequency {0.11} ±SPEED_REF_MAX rpm RO Bi FI NC PT
5.02 Output voltage 0 to AC_VOLTAGE_MAX V
RO Uni FI NC PT
5.03 Output power ±POWER_MAX kW
RO Bi FI NC PT
5.05 D.C bus voltage 0 to +DC_VOLTAGE_MAX V
RO Uni FI NC PT
5.07 Motor rated current {0.46} 0 to RATED_CURRENT_MAX A Drive rated current [11.32] RW Uni RA US
5.08 Rated speed 0.00 to 40,000.00 rpm 3,000.00 RW Uni US
5.09 Rated voltage {0.44} 0 to AC_VOLTAGE_SET_MAX V
200 V drive: 230
400 V drive: EUR> 400, USA> 460
RW Uni RA US
5.11 Number of motor poles {0.42} Auto to 120 Pole (0 to 60) 6 POLE (3) RW Txt US
5.12 Autotune {0.40} SV> 0 to 6 0 RW Uni NC
5.14 Action on enable nonE (0), Ph EnL (1), Ph Init (2) nonE(0) RW Txt US
5.17 Motor stator resistance
0.000 to 65.000 x 10
Ω
0.0 RW Uni RA US
5.18
Maximum switching
frequency
{0.41} 0 to 4 (3, 4, 6, 8, 12 kHz) 2 (6 kHz) RW Txt RA US
5.21 Field gain reduction OFF (0) or On (1) OFF (0) RW Bit US
5.22
High speed servo mode
enable
OFF (0) or On (1) 0 RW Bit US
5.24
Transient inductance (
σL
s
)
0.000 to 500.000 mH 0.000 RW Uni RA US
5.26
High dynamic performance
enable
OFF (0) or On (1) OFF (0) RW Bit US
5.31 Voltage controller gain 0 to 30 1 RW Uni US
5.32
Motor torque per amp, K
t
0.00 to 500.00 N m A
-1
1.60 RW Uni US
5.33
Motor volts per 1,000 rpm, K
e
0 to 10,000 V 98 RW Uni US
5.35
Disable auto switching
frequency change
OFF (0) or On (1) OFF (0) RW Bit US
5.36 Motor pole pitch 0 to 655.35 mm 0.00 RW Uni US
5.37 Actual switching frequency
3 (0), 4 (1), 6 (2), 8 (3), 12 (4), 16 (5), 6 rEd (6),
12 rEd (7)
RO Txt NC PT
5.38 Minimal movement phasing test angle
0.0 to 25.5
°
5.0 RW Uni US
5.39
Minimal movement phasing
test pulse length
0 to 3 0 RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
