Emerson Digitax ST User Manual

Safety
Information
Product
information
Mechanical
installation
Electrical
installation
Getting
started
Basic
parameters
Running the
motor
Optimization
EtherCAT
interface
SMARTCARD
Operation
Onboard
PLC
Advanced
parameters
Technical
Data
Diagnostics
UL listing
information
Digitax ST User Guide 197
Issue: 5
*If a tunE through tunE7 trip occurs, then after the drive is reset the drive cannot be made to run unless it is disabled via the Safe Torque Off input
(terminal 31), drive enable parameter (Pr 6.15) or the control word (Pr 6.42 and Pr 6.43).
Table 14-2 Serial communications look-up table
The trips can be grouped into the following categories. It should be noted that a trip can only occur when the drive is not tripped or is already tripped
but with a trip with a lower priority number.
UP udF Onboard PLC program un-defined trip
97 Check program
UP uSEr Onboard PLC program requested a trip
96 Check program
UV DC bus under voltage threshold reached
1
Check AC supply voltage level
Drive voltage rating (Vac) Under voltage threshold (Vdc) UV reset voltage (Vdc)
200 175 215
400 330 425
Trip Diagnosis
No. Trip No. Trip No. Trip
1
UV 90 UP div0 181 C.Rdo
2
OV 91 UP PAr 182 C.Err
3
OI.AC 92 UP ro 183 C.dAt
4
OI.br 93 UP So 184 C.FULL
5
PS 94 UP ovr 185 C.Acc
6
Et 95 UP OFL 186 C.rtg
7
O.SPd 96 UP uSEr 187 C.TyP
8
PS.10V 97 UP udF 188 C.cPr
9
PS.24V 98 UP ACC 189 EnC1
10
br.th 99 t099 190 EnC2
11
tunE1 100 Reserved 191 EnC3
12
tunE2 101 t101 192 EnC4
13
tunE3 102 Reserved 193 EnC5
14
tunE4 103 Reserved 194 EnC6
15
tunE5 104 Reserved 195 EnC7
16
tunE6 105 Reserved 196 EnC8
17
tunE7 106 Reserved 197 EnC9
18
tunE 107 Reserved 198 EnC10
19
It.br 108 Reserved 199 dESt
20
It.AC 109 Reserved 200 SL1.HF
21
O.ht1 110 Reserved 201 SL1.tO
22
Reserved 111 Reserved 202 SL1.Er
23
Reserved 112 to 160 t112 to t160 203 SL1.nF
24
th 161 Enc11 204 SL1.dF
25
thS 162 Enc12 205 SL2.HF
26
O.Ld1 163 Enc13 206 SL2.tO
27
O.ht3 164 Enc14 207 SL2.Er
28
cL2 165 Enc15 208 SL2.nF
29
cL3 166 Enc16 209 SL2.dF
30
SCL 167 Enc17 210 SL3.HF
31
EEF 168 to 171 t168 to t171 211 SL3.tO
32
PH 172 C.SL1 212 SL3.Er
33
rS 173 C.SL2 213 SL3.nF
34
PAd 174 C.SL3 214 SL3.dF
35
CL.bit 175 C.Prod 215 SL.rtd
36
SAVE.Er 176 EnP.Er 216 t216
37
PSAVE.Er 177 C.boot 217 to 232 HF17 to HF232
38
t038 178 C.bUSY
39 Reserved 179 C.Chg
40 to 89
t040 to t089 180 C.OPtn
