202 Digitax ST User Guide
Issue: 5
Table 14-23 Error codes
Error Code Meaning Corresponding Drive Trip Code
0x0000 Error reset / No error 0 – No trip
0x1000 Generic error (Any trip code not elsewhere in table)
0x2200 Internal current 109 - OIdC.P
0x2300 Current, device output side
3 – OI.AC
20 – It.AC
104 - OIAC.P
0x3000 Voltage 8 – PS.10V
0x3130 Phase failure
32 – PH
107 – PH.P
0x3200 Voltage inside the device
1 – UU
2 – OU
5 – PS
9 – PS.24V
108 – PS.P
0x3210 dc bus over-voltage 106 - OV.P
0x4200 Temperature device
21 – O.ht1
22 – O.ht2
23 – O.CtL
27 – O.ht3
102 – Oht4.P
105 – Oht2.P
0x5000 Device hardware
200 – SL1.HF, 201 – SL1.t0, 202 – SL1.Er, 203 – SL1.nF, 204 – SL1.dF
205 – SL2.HF, 206 – SL2.t0, 207 – SL2.Er, 208 – SL2.nF, 209 – SL2.dF
210 – SL3.HF, 211 – SL3.t0, 212 – SL3.Er, 213 – SL3.nF, 214 – SL3.dF
215 – SL.rtd, 217 – HF17, 218 – HF18, 219 – HF19, 220-232 – HF20-HF32
0x5530 Data Storage (Non-volatile data memory)
31 – EEF
36 – SAVE.Er
37 – PSAVE.Er
0x6200 Device Software (User Software)
10 – t010
32 – t038
40 to 89 – t040 to t089
90 to 99 – UP --- / t090 to t099
101 – t101
112 to 160 – t112 to t160
168 to 174 – t168 to t174
216 – t216
0x6320 Parameter Error 199 - dESt
0x7112
Brake Chopper (Over current brake
chopper)
4 – OI.br
19 – It.br
103 – OIbr.P
0x7200 Measurement Circuit 33 – rS
0x7300 Sensor
14 – tunE4
15 – tunE5
16 – tunE6
161 to 167 – Enc11 to Enc17
176 – EnP.Er
189 – Enc1 (SP Only)
190 to 198 – Enc2 to Enc10
0x7510 Communication (Serial Interface 1) 30 – SCL
0x7600 Additional Modules (Data storage)
175 – C.Prod
177 – C.boot
178 – c.bUSY
179 – C.Chg
180 – C.OPtn
181 – C.RdO
182 – C.Err
183 – C.dAt
184 – C.FULL
185 – C.Acc
186 – C.rtg
187 – C.TyP
188 – C.cPr
0x9000 External Error 6 – Et
