Digitax ST User Guide 35
Issue: 5
4.14.1 Control terminal specification
T8 analog input 3 has a parallel connection to terminal 15 of the drive
input encoder connector.
1 0V common
Function
Common connection for all external
devices
2 +24 V external input
Function
To supply the control circuit
without providing a supply to the
power stage
Nominal voltage +24.0 Vdc
Minimum continuous
operating voltage
+19.2 Vdc
Maximum continuous
operating voltage
+30.0 Vdc
Minimum start-up voltage 21.6 Vdc
Recommended power supply 60 W 24 Vdc nominal
Recommended fuse 3 A, 50 Vdc
3 0V common
Function
Common connection for all external
devices
4 +10V user output
Function Supply for external analog devices
Voltage tolerance ±1 %
Maximum output current 10 mA
Protection Current limit and trip @ 30 mA
Precision reference Analog input 1
5 Non-inverting input
6 Inverting input
Default function Speed reference
Type of input
Bipolar differential analog
(For single-ended use, connect
terminal 6 to terminal 3)
Full scale voltage range ±9.8 V ±1 %
Absolute maximum
voltage range
±36 V relative to 0V
Working common mode
voltage range
±13 V relative to 0V
Input resistance 100 kΩ ±1%
Resolution 16-bit plus sign (as speed reference)
Monotonic Yes (including 0V)
Dead band None (including 0V)
Jumps None (including 0V)
Maximum offset 700 μV
Maximum non linearity 0.3 % of input
Maximum gain asymmetry 0.5 %
Input filter bandwidth single
pole
~1 kHz
Sampling period
250 μs with destinations as Pr 1.36,
Pr 1.37 or Pr 3.22.
7 Analog input 2
Default function Speed reference
Type of input
Bipolar single-ended analog voltage
or unipolar current
Mode controlled by... Pr 7.11
Operating in Voltage mode
Full scale voltage range ±9.8 V ±3 %
Maximum offset ±30 mV
Absolute maximum
voltage range
±36 V relative to 0V
Input resistance >100 kΩ
Operating in current mode
Current ranges
0 to 20 mA ±5 %, 20 to 0 mA ±5 %,
4 to 20 mA ±5 %, 20 to 4 mA ±5 %
Maximum offset 250 μA
Absolute maximum voltage
(reverse bias)
−36 V max
Absolute maximum current +70 mA
Equivalent input resistance ≤200 Ω at 20 mA
Resolution 10 bit + sign
Sample period
250 μs when configured as voltage
input with destinations as Pr 1.36,
Pr 1.37, Pr 3.22 or Pr 4.08.
8 Analog input 3
Default function Motor thermistor input (PTC)
Type of input
Bipolar single-ended analog voltage,
unipolar current or motor thermistor
input
Mode controlled by... Pr 7.15
Operating in Voltage mode (default)
Voltage range ±9.8 V ±3 %
Maximum offset ±30 mV
Absolute maximum
voltage range
±36 V relative to 0V
Input resistance >100 kΩ
Operating in current mode
Current ranges
0 to 20 mA ±5 %, 20 to 0 mA ±5 %,
4 to 20 mA ±5 %, 20 to 4 mA ±5 %
Maximum offset 250 μA
Absolute maximum voltage
(reverse bias)
−36 V max
Absolute maximum current +70 mA
Equivalent input resistance ≤200 Ω at 20 mA
Operating in thermistor input mode
Internal pull-up voltage <5 V
Trip threshold resistance 3.3 kΩ ±10 %
Reset resistance 1.8 kΩ ±10 %
Short-circuit detection
resistance
50 Ω ±30 %
Resolution 10 bit + sign
Sample period
250 μs when configured as voltage
input with destinations as Pr 1.36,
Pr 1.37, Pr 3.22 or Pr 4.08.
