78 Digitax ST User Guide
Issue: 5
Table 9-19 TxPDO mapping 1
Table 9-20 TxPDO mapping 2
Table 9-21 TxPDO mapping 3
Table 9-22 TxPDO mapping 6
0x1A00 Transmit PDO mapping 1
Sub-index 0: Number of mapped objects
Access: RW Range: 0 to (CF) Size: 1 byte Unit: N/A
Default: 1
Description: The number of mapped objects in thie PDO
Sub-index 1: 1st mapped object
Access: RW
Range: 0 to
0xFFFFFFFF
Size: 4 bytes Unit: N/A
Default: 0x60410010 - the DSP-402 status word (0x6041)
Description:
A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-
bit parameter would have a length of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
0x1A01 Transmit PDO mapping 2
Sub-index 0: Number of mapped objects
Access: RW Range: 0 to (CF) Size: 1 byte Unit: N/A
Default: 2
Description: The number of mapped objects in this PDO.
Sub-index 1: 1st mapped object
Access: RW
Range: 0 to
0xFFFFFFFF
Size: 4 bytes Unit: N/A
Default: 0x60410010 - the DSP-402 status word (0x6041)
Description:
A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-
bit parameter would have a length of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Sub-index 2: 2nd mapped object
Access: RW
Range: 0 to
0xFFFFFFFF
Size: 4 bytes Unit: N/A
Default:
0x60610008 - the DSP-402 modes of operation display
object (0x6061)
Description:
A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-
bit parameter would have a length of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
0x1A02 Transmit PDO mapping 3
Sub-index 0: Number of mapped objects
Access: RW Range: 0 to (CF) Size: 1 byte Unit: N/A
Default: 2
Description: The number of mapped objects in this PDO.
Sub-index 1: 1st mapped object
Access: RW
Range: 0 to
0xFFFFFFFF
Size: 4 bytes Unit: N/A
Default: 0x60410010 - the DSP-402 status word (0x6041)
Description:
A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-
bit parameter would have a length of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Sub-index 2: 2nd mapped object
Access: RW
Range: 0 to
0xFFFFFFFF
Size: 4 bytes Unit: N/A
Default: 0x60640020 - the DSP-402 actual position (0x6064)
Description:
A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-
bit parameter would have a length of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
0x1A05 Transmit PDO mapping 6
Sub-index 0: Number of mapped objects
Access: RW Range: 0 to (CF) Size: 1 byte Unit: N/A
Default: 2
Description: The number of mapped objects in this PDO.
Sub-index 1: 1st mapped object
Access: RW
Range: 0 to
0xFFFFFFFF
Size: 4 bytes Unit: N/A
Default: 0x60410010 - the DSP-402 status word (0x6041)
Description:
A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-
bit parameter would have a length of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
Sub-index 2: 2nd mapped object
Access: RW
Range: 0 to
0xFFFFFFFF
Size: 4 bytes Unit: N/A
Default: 0x60440010 - the DSP-402 actual motor speed (0x6044).
Description:
A mapping to an object with the following format:
Bits 0 to 7: Length of the mapped object in bits, e.g. a 32-
bit parameter would have a length of 32 or 0x20.
Bits 8 to 15: Sub-index of the mapped object.
Bits 16 to 31: Index of the mapped object.
