1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 43/56
Mess.
Errata
Corrige
Too Many dGS
output
More than one oAi has
been set as dGs (digital
scroll)
• Check the oAi parameters and set
them different from dGS.
Too Many dGSt
output
One oAi has been set as
dGst (triac for digital
scroll)
• Check the oAi parameters and set
them different from dGSt.
Too Many 6dG
output
More than one oAi has
been set as 6dG (triac for
digital scroll)
• Check the oAi parameters and set
them different from 6dG.
6dG bEForE
dGS ConFig
Error
oAi configured as 6dG
before the dGS
• Check the oAi parameters and set
6dG after dGS.
dGSt OutPut
Error
One oAi has been set as
dGst (triac for digital
scroll)
• Check the oAi parameters and set
them different from dGSt.
dGS not
PrESEnt
One oAi has been set as
dGs (digital scroll)
• Check the oAi parameters and set
them different from dGS.
dGSt not
PrESEnt
The digital output for
digital compressor has
not be set
• Check the oAi parameters and set
them different from dGS or 6dG.
StEP ConFiG
Error
Load (step) configuration
error
• A relay oA(i) has been set as step
without a previous relay oA(i-1) has
been set as compressor. EI oA1 = StP
Fan ProbE not
PrESEnt
None probe has been set
for to manage the fan
Check parameters FPb , P1C , P2C ,
P3C, and then set a probe for this
function
No P3 ProbE For
Lin out
None probe has been set
for the Liquid Injection
function
Check parameters LiPr , P3C , P4C, and
then set a probe for this function.
no LoAdS For
rEGuLAtion
None oA(i) is set as
compressors or fans
• Check the setting of oA1,oA2, oA3,
oA4,oA5, oA6 parameters
ProbE tyPE For
dynAMic Set
A current of voltage
transducer has been set
for the “Dynamic set point
for fan” function
• Set a temperature probe for the
“Dynamic set point for fan” function,
par. “dSEP”
No ProbE For
dynAMic Set
None probe has been set
for the “Dynamic set point
for fan” function
• Set a temperature probe for the
“Dynamic set point for fan” function,
par. “dSEP”.
too MAnY InC1
More than one oAi has
been set as inC1 (inverter
for suction 1)
• Check the oAi parameters and set only
1 as “inC1”.
No AnALoGuE
out For InC1
None analogue output
has been set as “inC1”
• Check AoF and 2AoF and set one of
them as “inC1”
too MAnY InC2
More than one oAi has
been set as inC2 (inverter
for suction 2)
• Check the oAi parameters and set only
1 as “inC2”.
No AnALoGuE
out For InC2
None analogue output
has been set as “inC2”
• Check AoF and 2AoF and set one of
them as “inC2”
too MAnY InF
More than one oAi has
been set as inF (inverter
for fan)
• Check the oAi parameters and set only
1 as “inF”.
No AnALoGuE
out For InF
None anlogue output has
been set as “inF”
• Check AoF and 2AoF and set one of
them as “inF”
