1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 46/56
23.2 Buzzer muting
Press any buttons to silence the buzzer during an alarm condition.
Hold pressed for more than 3 seconds switch off the alarm relay during an alarm condition
23.3 Alarm conditions – summary table
Low
electronic
pressure-
switch alarm,
suction 1
(suction 2)
Pressure/temperat
ure less than
ELP(ELP2) value
All compressors of
the circuit 1 (2) are
turned off. Fans
unchanged.
Automatically when the pressure/temperature
increases more than ELP (ELP2) value
Low
pressure-
switch alarm,
suction 1
(suction 2)
Low pressure
switch input of
circuit 1 (2)
enabled
All compressors of
the circuit 1 (2) are
turned off. Fans
unchanged.
Automatically (if the number of activation are
less than PEn in the PEi time) when the input is
disable.
- The compressors restarts working
according to the working algorithm.
Manually (if PEn activation happened in the PEi
time)
When the input is disable:
a. hold pressed the Restart(DOWN)key for 3s
or
b. turn off and on the instrument..
- The compressors restarts working
according to the working algorithm.
High
pressure
switch alarm
High pressure
switch input
enabled
- All
compressors
are turned off.
- All fans are
turned on.
Automatically (if the number of activation are
less than PnF in the PiF time) when the input is
disable.
- Compressors and fans restart working
according to the working algorithm.
Manually (if PnF activation happened in the PiF
time)
When the input is disable:
- hold pressed the Restart(DOWN) key for
3s or
- turn off and on the instrument.
Compressors and fans restarts working according
to the working algorithm.
Probe failure or out
of range
− The
compressors
are activated
according to the
SPr or PoPr
parameters.
Automatically as soon as the probe restarts
working.
Probe failure or out
of range
− The fans are
activated
according to the
FPr
parameters.
Automatically as soon as the probe restarts
working.
