Emerson dixell XC650CX User Manual

1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 50/56
25. Parameters – Default values
Label
Value
Menu
Description
Range
StC1
-10.0
Pr1
Set point for compressors
LSE÷HSE
StC2
-30.0
Pr1
Set point for compressors circit 2
2LSE÷2HSE
SEtF
35.0
Pr1
Set point for fans
LSF÷HSF
OA1
CPr1
Pr2
Load 1 configuration
nu - CPr1 - CPr2 - StP - dGS - 6dG -
dGSt - InC1 - InC2 - FAn - InF - LIn – ALr
– Liq - HGi
OA2
CPr1
Pr2
Load 2 configuration
nu - CPr1 - CPr2 - StP - dGS - 6dG -
dGSt - InC1 - InC2 - FAn - InF - LIn – ALr
– Liq - HGi
OA3
CPr1
Pr2
Load 3 configuration
nu - CPr1 - CPr2 - StP - dGS - 6dG -
dGSt - InC1 - InC2 - FAn - InF - LIn – ALr
– Liq - HGi
OA4
FAn
Pr2
Load 4 configuration
nu - CPr1 - CPr2 - StP - dGS - 6dG -
dGSt - InC1 - InC2 - FAn - InF - LIn – ALr
– Liq - HGi
OA5
FAn
Pr2
Load 5 configuration
nu - CPr1 - CPr2 - StP - dGS - 6dG -
dGSt - InC1 - InC2 - FAn - InF - LIn – ALr
– Liq - HGi
OA6
ALr
Pr2
Load 6 configuration
nu - CPr1 - CPr2 - StP - dGS - 6dG -
dGSt - InC1 - InC2 - FAn - InF - LIn – ALr
– Liq - HGi
CtyP
SPo
Pr2
Compressor type
SPo, dPo, Scr
StP
oP
Pr2
Valve output polarity
OP - CL
PC1
20
Pr2
Capacity of compressor 1
0÷100
PC2
20
Pr2
Capacity of compressor 2
0÷100
PC3
20
Pr2
Capacity of compressor 3
0÷100
PC4
20
Pr2
Capacity of compressor 4
0÷100
PC5
20
Pr2
Capacity of compressor 5
0÷100
PC6
20
Pr2
Capacity of compressor 6
0÷100
FtyP
404
Pr2
Refrigerant gas type
r22= R22; r134=134, r404=R404A; - 407A
= r407A; 407C= r407C; 407F= r407F;
410= r410; 507=R507; CO2= CO2; r32 =
r32; r290 = r290; r448 = r448A; r449 =
r449A, r450 = r450A, r452A, r513= r513;
1234 = r1234ze
Sty
yES
Pr2
Compressor Sequence type
no - yES
Rot
yES
Pr2
Fan Sequence type
no - yES
P1C
Cur
Pr2
P1 probe setting (4/20mA, 0-5V, ntc)
nP - Cur - tEn - ntc
PA04
-0.5
Pr2
4mA or 0.5V readout for P1 probe
(-1.0 ÷ PA20)BAR; (-15 ÷ PA20)PSI; (-
100 ÷ PA20)KPA
PA20
11.0
Pr2
20mA or 4.5V readout for P1 probe
(PA04 ÷ 61.0)BAR; (PA04 ÷ 885)PSI;
(PA04 ÷ 6100)KPA
CAL
0.0
Pr2
P1 probe offset
-12.0÷12.0(°C); -20÷20 (°F); 12.0÷12.0
(bar); - 200÷200 (PSI) -999÷999 (kPA)
P2C
Cur
Pr2
P2 probe setting (4/20mA, 0-5V, ntc)
nP - Cur - tEn - ntc
FA04
0.0
Pr2
4mA or 0.5V readout for P2 probe
(-1.0 ÷ FA20)BAR; (-15 ÷ FA20)PSI; (-
100 ÷ FA20)KPA
FA20
30.0
Pr2
20mA or 4.5V readout for P2 probe
(FA04 ÷ 61.0)BAR; (FA04 ÷ 885)PSI;
(FA04 ÷ 6100)KPA
FCAL
0.0
Pr2
P2 probe offset
-12.0÷12.0(°C); -20÷20 (°F); 12.0÷12.0
(bar);
- 200÷200 (PSI) -999÷999 (kPA)
P3C
nP
Pr2
P3 probe setting (4/20mA, 0-5V, ntc)
nP - Cur - tEn - nt10 - nt86
