1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 51/56
Label
Value
Menu
Description
Range
3P04
-0.5
Pr2
4mA or 0.5V readout for P3 probe
(-1.0 ÷ FA20)BAR; (-15 ÷ FA20)PSI; (-
100 ÷ FA20)KPA
3P20
11.0
Pr2
20mA or 4.5V readout for P3 probe
(3P04 ÷ 61.0)BAR; (3P04 ÷ 885)PSI;
(3P04 ÷ 6100)KPA
O3
0.0
Pr2
P3 probe offset
-12.0÷12.0(°C); -20÷20 (°F); 12.0÷12.0
(bar); - 200÷200 (PSI) -999÷999 (kPA)
P4C
nP
Pr2
P4 probe setting (NTC 10K, NTC 86K)
nP - nt10 - nt86-ntcH
O4
0.0
Pr2
P4 probe offset
-12.0÷12.0(°C); -20÷20 (°F)
2CPb
nP
Pr2
Probe selection for second suction
circuit
nP - P1 - P2 - P3
FPb
P2
Pr2
Probe setting for fan
nP - P1 - P2 - P3
iF01
oA1
Pr2
Digital input 1 function
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6
- InF - LP1 - LP2 - HP - ES - OFF - LL -
SIL – EAL – Co1 – Co2 – Co3 – Co4 –
Co5 – Co6
iF02
oA2
Pr2
Digital input 2 function
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6
- InF - LP1 - LP2 - HP - ES - OFF - LL -
SIL – EAL – Co1 – Co2 – Co3 – Co4 –
Co5 – Co6
iF03
oA3
Pr2
Digital input 3 function
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6
- InF - LP1 - LP2 - HP - ES - OFF - LL -
SIL – EAL – Co1 – Co2 – Co3 – Co4 –
Co5 – Co6
iF04
oA4
Pr2
Digital input 4 function
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6
- InF - LP1 - LP2 - HP - ES - OFF - LL -
SIL – EAL – Co1 – Co2 – Co3 – Co4 –
Co5 – Co6
iF05
LP1
Pr2
Digital input 5 function
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6
- InF - LP1 - LP2 - HP - ES - OFF - LL -
SIL – EAL – Co1 – Co2 – Co3 – Co4 –
Co5 – Co6
iF06
HP
Pr2
Digital input 6 function
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6
- InF - LP1 - LP2 - HP - ES - OFF - LL -
SIL – EAL – Co1 – Co2 – Co3 – Co4 –
Co5 – Co6
iF07
oA5
Pr2
Digital input 7 function
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6
- InF - LP1 - LP2 - HP - ES - OFF - LL -
SIL – EAL – Co1 – Co2 – Co3 – Co4 –
Co5 – Co6
iP01
cL
Pr2
Safety input for Load 1 polarity (13-14):
OP - CL
iP02
cL
Pr2
Safety input for Load 2 polarity (13-15):
OP - CL
iP03
cL
Pr2
Safety input for Load 3 polarity (16-17):
OP - CL
iP04
cL
Pr2
Safety input for Load 4 polarity (16-18):
OP - CL
iP05
cL
Pr2
Safety input for Load 5 polarity (19-20):
OP - CL
iP06
cL
Pr2
Safety input for Load 6 polarity (19-21):
OP - CL
iP07
cL
Pr2
Configurable digital input i1F polarity (22-23):
OP - CL
d1d
0
Pr2
Dig. input set as oA1 or Co1 activation delay
0 ÷ 255 (sec)
d2d
0
Pr2
Dig. input set as oA2 or Co2 activation delay
0 ÷ 255 (sec)
d3d
0
Pr2
Dig. input set as oA3 or Co3 activation delay
0 ÷ 255 (sec)
d4d
0
Pr2
Dig. input set as oA4 or Co4 activation delay
0 ÷ 255 (sec)
d5d
0
Pr2
Dig. input set as oA5 or Co5 activation delay
0 ÷ 255 (sec)
d6d
0
Pr2
Dig. input set as oA6 or Co6 activation delay
0 ÷ 255 (sec)
did
20
Pr2
Liquid level alarm, signaling delay
0 ÷ 255 (min.)
didA
20
Pr2
External alarm, signaling delay:
0 ÷ 255 (min.)
ALMr
no
Pr2
Manual reset for compressor/fan alarms
no - yES
dEU
tPr
Pr2
Displaying measurement unit: pressure or
temperature
tMP - PrS
