Emerson dixell XC650CX User Manual

1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 52/56
Label
Value
Menu
Description
Range
CF
°C
Pr2
Measurement unit for temperature
°C - °F
PMU
Bar
Pr2
Measurement unit for pressure
BAr - PSI - PA
rES
dE
Pr2
Resolution for display and parameters
in - dE
dEU1
tPr
Pr2
Upper display: pressure or temperature
selection
tMP - PrS
dSP2
P2
Pr2
Lower display default visualization
nu - P1 - P2 - P3 - P4 - StC1 - StC2 -
SEtF
dEU2
tPr
Pr2
Lower display: pressure or temperature
selection
tMP - PrS
Pbd
5.0
Pr2
Proportional band for compressors regulation,
suction 1
0.1÷30.0(°C); 1÷50 (°F); 0.1÷10.0(BAR);
1÷150(PSI) 10÷1000(KPA)
rS
0.0
Pr2
Band offset, suction 1
-12.0÷12.0(°C) -20÷20(°F)
-12.0÷12.0(BAR); -200÷ 200(PSI)
-999÷999(KPA)
inC
500
Pr2
Integral time, suction 1
0 ÷ 999 sec
2Pbd
5.0
Pr2
Proportional band for compressors regulation,
suction 2
0.1÷30.0(°C); 1÷50 (°F); 0.1÷10.0(BAR);
1÷150(PSI) 10÷1000(KPA)
2rS
0.0
Pr2
Band offset, suction 2
-12.0÷12.0(°C) -20÷20(°F)
-12.0÷12.0(BAR); -200÷ 200(PSI)
-999÷999(KPA)
2inC
500
Pr2
Integral time, suction 2
0 ÷ 999 sec
ton
60
Pr2
Time with Inverter at maximum capacity before
starting a new load
0÷255s
toF
30
Pr2
Time with Inverter at minimum capacity before
starting a new load
0÷255s
ESC
0.0
Pr1
Energy saving for compressors regulation
-50.0÷50.0(°C) -90÷90(°F)
-20.0÷20.0(BAR) -300÷300(PSI)
-2000÷2000(KPA)
2ESC
0.0
Pr1
Energy saving for compressors regulation,
circuit 2
-50.0÷50.0(°C) -90÷90(°F)
-20.0÷20.0(BAR) -300÷300(PSI)
-2000÷2000(KPA)
OnOn
5
Pr2
Minimum delay between 2 switching on of the
same compressor
0 ÷ 255 (min.)
OFOn
1
Pr2
Delay between the switching off and on of the
same compressor
0 ÷ 255 (min.)
don
01:00
Pr2
Time delay between the insertion of two
different loads
0 ÷ 99.5 (min.10sec)
doF
00:30
Pr2
Time delay between switching off of two
different compressors
0 ÷ 99.5 (min.10sec)
donF
1:00
Pr2
Minimum time a stage stays ON
0 ÷ 99.5 (min.10sec)
MAon
0
Pr2
Maximum time a stage stays switched ON
0 ÷ 24 (hour)
FdLy
no
Pr2
'don' delay enabled also for the first request
no - yES
FdLF
no
Pr2
'doF' delay enabled also for the first switching
off
no - yES
odo
20
Pr2
Regulation delay at power on
0 ÷ 255 (sec.)
LSE
-40.0
Pr2
Minimum set point (compressors)
-50.0÷HSE(°C) -58.0÷HSE(°F)
PA04÷HSE(BAR,PSI,KPA)
HSE
10.0
Pr2
Maximum set point (compressors)
LSE÷150.0(°C) LSE÷302(°F)
LSE÷PA20(BAR , PSI , KPA)
2LSE
-40.0
Pr2
Minimum set point compressors, for circuit 2
-50.0÷2HSE(°C) -58.0÷2HSE(°F)
3P04÷2HSE(BAR,PSI,KPA)
2HSE
10
Pr2
Maximum set point compressors for circuit 2
LSE÷150.0(°C) LSE÷302(°F)
LSE÷3P20(BAR , PSI , KPA)
Lit
90.0
Pr2
Set point for liquid injection
0.0 ÷ 180.0°(°C) 32 ÷ 356(°F)
Lid
10.0
Pr2
Differential for liquid injection
0.1 ÷ 25.5° (°C) 1 ÷ 50° (°F)
LiPr
nP
Pr2
Probe selection for liquid injection
nP - P3 - P4
