1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 53/56
Label
Value
Menu
Description
Range
Pb
5.0
Pr2
Proportional band for fan regulation
0.1÷30.0(°C) 1÷50 (°F) 0.1÷10.0(BAR)
1÷150(PSI) 10÷1000(KPA)
ESF
0.0
Pr2
Energy saving differential for fan regulation
-50.0÷50.0(°C) -90÷90(°F)
-20.0÷20.0(BAR) -300÷300(PSI)
-2000÷2000(KPA)
PbES
0.0
Pr2
Band offset for fan regulation in ES
-50.0÷50.0(°C) -90÷90(°F)
-20.0÷20.0(BAR) -300÷300(PSI)
-2000÷2000(KPA)
Fon
30
Pr2
Time delay between the insertion of two
different fan
0 ÷ 255 (sec)
FoF
15
Pr2
Time delay between switching off of two
different fan
0 ÷ 255 (sec)
LSF
10.0
Pr2
Minimum set point (fan)
-50.0÷HSF(°C) -58.0÷HSF(°F)
FA04(FPb)÷HSF(BAR , PSI , KPA)
HSF
50.0
Pr2
Maximum set point (fan)
LSF÷150.0(°C) LSF÷302(°F) LSF÷FA20
(BAR , PSI , KPA)
PAO
30
Pr2
Alarm probe delay at power on
0 ÷ 255 (min.)
LAL
-40.0
Pr1
Pressure alarm set low limit (compressors)
-50.0÷HAL(°C); -58÷HAL(°F);
PA04÷HAL(BAR , PSI , KPA)
HAL
10.0
Pr1
Pressure alarm set high limit (compressors)
LAL÷150.0(°C); LAL÷302(°F);
LAL÷PA20(BAR , PSI , KPA)
tAo
15
Pr1
Pressure/temperature alarm delay
(compressors)
0 ÷ 255 (min.)
ELP
-45.0
Pr2
Electronic pressure switch threshold
-50.0÷STC1(°C) -58÷STC1(°F)
PA04÷STC1(BAR , PSI , KPA)
2LAL
-50.0
Pr2
Pressure alarm set low limit, , suction 2
-50.0÷2HAL(°C); -58÷2HAL(°F);
3PA4÷2HAL(BAR , PSI , KPA)
2HAL
20.0
Pr2
Pressure alarm set high limit, suction 2
2LAL÷150.0(°C); 2LAL÷302(°F);
2LAL÷3P20(BAR , PSI , KPA)
2tAo
15
Pr2
Pressure/temperature alarm delay , suction 2
0 ÷ 255 (min.)
2ELP
-50.0
Pr2
Electronic pressure switch threshold, suction 2
-50.0÷STC2(°C) -58÷STC2(°F)
3P04÷STC2(BAR , PSI , KPA)
SEr
999
Pr2
Working hour alarm set (tenth of ours)
1 ÷ 999 (0= disabled) (10 hour)
PEn
5
Pr2
Low Pressure switch maximum activations
0 ÷ 15
PEI
60
Pr2
Low Pressure switch activations time
0 ÷ 255 (min.)
SPr
1
Pr2
Number of compressors ON with faulty probe
0 ÷ 6
2PEn
5
Pr2
Low Pressure switch maximum activations,
suction 2
0 ÷ 15
2PEI
60
Pr2
Low Pressure switch activations time, suction 2
0 ÷ 255 (min.)
2SPr
1
Pr2
Number of compressors ON with faulty probe,
suction 2
0 ÷ 6
dtL
110.0
Pr2
DLT high temperature alarm threshold
0÷180°C 32÷356°F
dLd
5
Pr2
DLT high temperature alarm delay
0÷15 (min.)
dLH
15.0
Pr2
DLT high temperature alarm differential for recovery
0.1÷25.5°C 1÷50°F
dtLi
nP
Pr2
Probe selection for DLT control
nP - P3 - P4 - P5
dtLP
50
Pr2
Compressors OFF in case of discharge line
temperature alarm
0÷80(%)
dtLF
YES
Pr2
Stop compressor in case of dtL alarm
no - yES
PoPr
50
Pr2
Capacity engaged with suction 1 probe failure
0÷100
LAF
0.0
Pr1
Low pressure alarm set (fan)
-50.0÷HAF(°C); -58÷HAF(°F);
FA04÷HAF(BAR , PSI , KPA)
HAF
60.0
Pr1
High pressure alarm set (fan)
LAF÷150.0(°C) LAF÷302(°F)
LAF÷FA20(BAR , PSI , KPA)
AFd
5
Pr2
Pressure alarm delay
0 ÷ 255 (min)
HFc
YES
Pr2
Compressor off with high pressure
(temperature) alarm
no – yES
dHF
5
Pr2
Interval between 2 compressors turning off with
high pressure (temperature) alarm
0 ÷ 255 (sec.)
