1592001431 XC650CX GB r3.5 21.07.2020 XC650CX 49/56
24. Technical features
XC650CX
Housing: Self-extinguishing PC/PC+ABS.
Case: Front panel 32x74 mm, depth 60mm.
Mounting device: panel mounting in a 29x71 mm panel cut-out
Degree of protection: Indoor use, Type 1 enclosure (NEMA - UL 50e);
Frontal panel: IP65; Rear housing: IP20.
Power supply: 12Vac/dc
10%, 50-60Hz.
Overvoltage Category: III.
Rated power: 5VA max.
Rated Impulse Voltage: 2500V
Display: 4-digit red led and 4-digit orange led.
Software class: A.
Terminal connections: Removable terminal block 12 and 14 ways.
Data storing: on the non-volatile memory (EEPROM).
Type of action: 1B.
Pollution degree: 2.
Ambient operating temperature: -10T60°C.
Shipping and storage temperature: -25÷60°C.
Relative humidity: 20
85% (no condensing)
Measurement range: NTC probe: -40÷110°C.
Resolution: 0.1°C or 1°C; Accuracy (ambient temp. 25°C): ±0,7°C ±1 digit
Inputs: up to 4 NTC probes, or up to 3 4÷20mA or up to 0.5÷4.5Vdc transducer.
Digital inputs: 7 free voltage inputs
Relay outputs: Resistive 3A, 120/240 Vac; Motor 1/10Hp, 120 Vac; 1/4Hp, 240 Vac; Pilot Duty
B300
Open collector: alarm output: 12V, 40mA.
Analogue output: 2 x 4÷20mA or 0÷10V (optional)
Serial output: TTL standard Communication protocol: ModBus – RTU.
Purpose of control: operating control.
Construction of control: incorporated control, intended to be used in Class I or Class II
equipment.
