Emerson FA-700 - Installation Details; Connecting to Phone Line

9
Plug phone cord
connector end here
Wall
Phone Jack
Plug phone cord
connector end here
2
1
Installing the batteries
Note: To avoid a false low battery alarm, please connect the AC power adapter to the FA-700
and the wall outlet before inserting batteries.
To install the batteries, follow the Steps shown in Figure 4.
Figure 4: Battery Installation Connections
Connecting to the standard phone line
To connect the FA-700 to a phone line, do the following:
Batteries
AA
AA
• Install the AA batteries as shown--
note the polarity.
• Replace the battery cover.
Step 1
• Press down on the cover and push
in the direction of the arrow to
loosen and remove the cover.
Step 2
