DVC6000 Digital Valve Controllers
September 2013
1-10
Table 1-6. Hazardous Area Classifications—ATEX
Certificate Type Certification Obtained Entity Rating Temperature Code
Enclosure
Rating
ATEX
DVC60x0
DVC60x0S
(x = 1,2,3)
II 1 G & D
Intrinsically Safe
Gas
Ex ia IIC T5/T6 Ga
Dust
Ex ia IIIC T85C (Ta ≤ +73C), T92C
(Ta ≤ +80C) Da
Per drawing GE60771
Natural Gas Approved
Ui = 30 VDC
Ii = 226 mA
Ci = 5 nF
Li = 0.55 mH
Pi = 1.4 W
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
IP66
Single Seal Device
II 2 G
Flameproof
Gas
Ex d IIC T5/T6 Gb
Natural Gas Approved
− − −
T5(Tamb ≤ 85C)
T6(Tamb ≤ 80C)
IP66
Single Seal Device
II 3 G
Type n
Gas
Ex nC IIC T5/T6 Gc
− − −
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
IP66
Single Seal Device
DVC6005
II 1 G & D
Intrinsically Safe
Gas
Ex ia IIC T5/T6 Ga
Dust
Ex ia IIIC T85C (Ta ≤ +76C), T89C
Ta ≤ +80C) Da
Per drawing GE60771
Natural Gas Approved
Ui = 30 VDC
Ii = 226 mA
Ci = 5 nF
Li = 0.55 mH
Pi = 1.4 W
Uo = 9.6 VDC
Io = 3.5 mA
Co = 3.6 uF
Lo = 100 mH
Po = 8.4 mW
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
IP66
Single Seal Device
II 2 G
Flameproof
Gas
Ex d IIC T5/T6 Gb
Natural Gas Approved
− − −
T5(Tamb ≤ 85C)
T6(Tamb ≤ 80C)
IP66
Single Seal Device
II 3 G
Type n
Gas
Ex nC IIC T5/T6 Gc
− − −
T5(Tamb ≤ 80C)
T6(Tamb ≤ 75C)
IP66
Single Seal Device
DVC60x5
(x = 1,2,3)
II 1 G & D
Intrinsically Safe
Gas
Ex ia IIC T4/T5/T6 Ga
Dust
Ex ia IIIC T85C (Tamb ≤ +64C) T100C
(Tamb ≤ +79C), T135C (Tamb ≤ +114C)
T146C (Tamb ≤ +125C) Da
Per drawing GE60771
Ui = 30 VDC
Ii = 100 mA
Ci = 0 uF
Li = 0 mH
Pi = 160 mW
T4(Tamb ≤ 125C)
T5(Tamb ≤ 95C)
T6(Tamb ≤ 80C)
IP66
II 2 G
Flameproof
Gas
Ex d IIC T4/T5/T6 Gb
− − −
T4(Tamb ≤ 125C)
T5(Tamb ≤ 95C)
T6(Tamb ≤ 80C)
IP66
II 3 G
Type n
Gas
Ex nA IIC T4/T5/T6 Gc
− − −
T4(Tamb ≤ 125C)
T5(Tamb ≤ 95C)
T6(Tamb ≤ 80C)
IP66
1

Emerson Fisher FIELDVUE DVC6000 Specifications

General

Model	DVC6000
Type	Digital Valve Controller
Manufacturer	Emerson
Operating Temperature	-40 to 85°C (-40 to 185°F)
Communication Protocols	HART
Power Supply	24 VDC
Ingress Protection	IP66
Weight	Approximately 2.3 kg (5.1 lb)
Input Signal	4-20 mA
Certifications	ATEX, IECEx, CSA, FM
Mounting	Directly to valve or pipe
