DVC6000f Digital Valve Controllers
December 2009
8-12
Figure 8-5. FIELDVUE DVC6005f Base Unit (continued)
APPLY LUB, SEALANT
NOTES:
SEE FIGURE 8-6 FOR GAUGE CONFIGURATIONS
2. APPLY LUBRICANT KEY 65 TO ALL O-RINGS UNLESS OTHERWISE SPECIFIED
49B3261-C SHT 2 & 3 / DOC
SECTION E‐E
PIPESTAND MOUNTING
WALL MOUNTING
OUTPUT A
SUPPLY
OUTPUT A
SUPPLY
OUTPUT B
OUTPUT B
1
1
E
E
8
