Emerson Fisher FIELDVUE DVC6000f User Manual

Parts
December 2009
8-13
Figure 8-6. Typical FIELDVUE DVC6000f Digital Valve Controller Gauge Configuration
APPLY LUB, SEALANT
SINGLE-ACTING DIRECT SINGLE-ACTING REVERSE
DOUBLE-ACTING
1
1
NOTE:
FOR SINGLE-ACTING DIRECT, OUTPUT B IS PLUGGED.
FOR SINGLE-ACTING REVERSE, OUTPUT A IS PLUGGED.
2
2
48B7710-K SHT 2 / DOC
Figure 8-7. FIELDVUE DVC6015 Digital Valve Controller Assembly
APPLY LUB, SEALANT
NOTE:
1. APPLY LUBRICANT KEY 65 TO ALL O-RINGS UNLESS OTHERWISE SPECIFIED
48B7986-A
SECTION A‐A
SECTION B‐B
SECTION D‐D
SECTION C‐C
8
