Transducer Block (TB) Menu Structure (Continued)
PARAMETER LABEL MENU STRUCTURE
Proximity Hi Alert TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Active.Proximity Hi Alert
Proximity Hi Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Enable.Proximity Hi Alert Enable
Proximity Hi Hi Alert TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Active.Proximity Hi Hi Alert
Proximity Hi Hi Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Enable.Proximity Hi Hi Alert Enable
Proximity Lo Alert TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Active.Proximity Lo Alert
Proximity Lo Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Enable.Proximity Lo Alert Enable
Proximity Lo Lo Alert TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Active.Proximity Lo Lo Alert
Proximity Lo Lo Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Prox Alerts > Proximity > Proximity Enable.Proximity Lo Lo Alert Enable
Push Down To TB > Configure/Setup > Detailed Setup > Valve and Actuator > Trim > Push Down To
Rated Travel TB > Configure/Setup > Detailed Setup > Valve and Actuator > Valve > Rated Travel
Relay Type TB > Configure/Setup > Detailed Setup > Instrument > Relay Type
Seat Type TB > Configure/Setup > Detailed Setup > Valve and Actuator > Trim > Seat Type
Setpoint TB > Device Variables > AO Control-Pre-Char > Setpoint
Setpoint Status TB > Device Variables > AO Control-Pre-Char > Setpoint Status
Setpoint(D) TB > Device Variables > DO Control > Setpoint(D)
Shaft Stem Diameter TB > Configure/Setup > Detailed Setup > Valve and Actuator > Valve > Shaft Stem Diameter
Simulate Active TB > Device Diagnostics > Status > Block Error > Block Error.Simulate Active
Simulate Jumper ON TB > Device Diagnostics > Status > Self Test Status > Self Test Status.Simulate Jumper ON
Spring Rate TB > Configure/Setup > Detailed Setup > Valve and Actuator > Actuator > Spring Rate
Spring Rate Units TB > Configure/Setup > Detailed Setup > Instrument > Spring Rate Units
Static Memory Alert TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Elect Active.Static Memory Alert
Static Memory Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Elect Enable.Static Memory Alert Enable
Static Memory Manual
Recovery
TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Shutdown Recovery.Static Memory
Manual Recovery
Static Memory Shutdown
TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Shutdown Trigger.Static Memory
Shutdown
Stroke Time Close TB > Configure/Setup > Detailed Setup > Valve and Actuator > Reference > Stroke Time Close
Stroke Time Open TB > Configure/Setup > Detailed Setup > Valve and Actuator > Reference > Stroke Time Open
Supply
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Supply Pressure > Supply
TB > Device Variables > Pressures > Supply
Supply Pressure Hi Alert
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Supply Pressure > Environment Active.Supply Pressure
Hi Alert
Supply Pressure Hi Alert Enable
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Supply Pressure > Environment Enable.Supply Pressure
Hi Alert Enable
Supply Pressure Hi Alert Point TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Supply Pressure > Supply Pressure Hi Alert Point
Supply Pressure Lo Alert
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Supply Pressure > Environment Active.Supply Pressure
Lo Alert
Supply Pressure Lo Alert
Enable
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Supply Pressure > Environment Enable.Supply Pressure
Lo Alert Enable
Supply Pressure Lo Alert Point TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Supply Pressure > Supply Pressure Lo Alert Point
Supply Pressure Sensor Alert
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Sensor Active. Supply Pressure Sensor
Alert
Supply Pressure Sensor Alert
Enable
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Sensor Enable. Supply Pressure Sensor
Alert Enable
Supply Sensor Failure TB > Device Diagnostics > Status > Self Test Status > Self Test Status.Supply Sensor Failure
Tag Description TB > Configure/Setup > Detailed Setup > Instrument > Tag Description
Temperature TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Temperature Limit > Temperature
Temperature Hi Alert
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Temperature Limit > Environment Active.Temperature Hi
Alert
Temperature Hi Alert Enable
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Temperature Limit > Environment Enable.Temperature
Hi Alert Enable
Temperature Hi Alert Point TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Temperature Limit > Temperature Hi Alert Point
Temperature Lo Alert
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Temperature Limit > Environment Active.Temperature Lo
Alert
Temperature Lo Alert Enable
TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Temperature Limit > Environment Enable.Temperature
Lo Alert Enable
Temperature Lo Alert Point TB > Configure/Setup > Detailed Setup > Alerts > Environment Alerts > Temperature Limit > Temperature Lo Alert Point
Temperature Sensor Alert
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Temperature Sensor > Sensor Active. Temperature Sensor
Alert
−Continued−
