Transducer Block (TB) Menu Structure (Continued)
PARAMETER LABEL MENU STRUCTURE
Output Block Timeout
Shutdown
TB > Configure/Setup > Detailed Setup > Alerts > Configuration Alerts > Output Block Timeout > Shutdown Recovery.Output
Block Timeout Manual Recovery
Packing Type TB > Configure/Setup > Detailed Setup > Valve and Actuator > Valve > Packing Type
PD Inside Status TB > Configure/Setup > Device Variables > PD Inside Status
PD Run TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > PD Run
Performance Critical Alert TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > Performance Active.Performance Critical Alert
Performance Critical Alert
Enable
TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > Performance Enable.Performance Critical Alert Enable
Performance Information Alert TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > Performance Active.Peformance Information Alert
Performance Information Alert
Enable
TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > Performance Enable.Peformance Information Alert
Enable
Performance Reduced Alert TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > Performance Active.Peformance Reduced Alert
Performance Reduced Alert
Enable
TB > Configure/Setup > Detailed Setup > Alerts > Performance Alerts > Performance Enable.Peformance Reduced Alert Enable
Performance Tuner
TB > Configure/Setup > Basic Setup > Performance Tuner
TB > Configure/Setup > Detailed Setup > Response Control > Travel Tuning > Performance Tuner
PlantWeb Alert Simulate TB > Configure/Setup > Detailed Setup > Alert Handling > PlantWeb Alert Simulate
Port Diameter TB > Configure/Setup > Detailed Setup > Valve and Actuator > Trim > Port Diameter
Port Type TB > Configure/Setup > Detailed Setup > Valve and Actuator > Trim > Port Type
Pressure A TB > Device Variables > Pressures > Pressure A
Pressure A Sensor Alert TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Sensor Active.Pressure A Sensor Alert
Pressure A Sensor Alert Enable
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Sensor Enable.Pressure A Sensor Alert
Enable
Pressure A Sensor Failure TB > Device Diagnostics > Status > Self Test Status > Self Test Status.Pressure A Sensor Error
Pressure A Sensor Manual
Recovery
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Shutdown Recovery.Pressure A Sensor
Manual Recovery
Pressure A Sensor Shutdown
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Shutdown Trigger.Pressure A Sensor
Shutdown
Pressure B TB > Device Variables > Pressures > Pressure B
Pressure B Sensor Alert TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Sensor Active.Pressure B Sensor Alert
Pressure B Sensor Alert Enable
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Sensors > Sensor Enable.Pressure B Sensor Alert
Enable
Pressure B Sensor Failure TB > Device Diagnostics > Status > Self Test Status > Self Test Status.Pressure B Sensor Error
Pressure Cutoff Closed TB > Configure/Setup > Detailed Setup > Response Control > Travel Pressure Control > Pressure Cutoff Closed
Pressure Cutoff Open TB > Configure/Setup > Detailed Setup > Response Control > Travel Pressure Control > Pressure Cutoff Open
Pressure Fallback Alert TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Fallback > Sensor Active.Pressure Fallback Alert
Pressure Fallback Alert Enable
TB > Configure/Setup > Detailed Setup > Alerts > Sensor Alerts > Pressure Fallback > Sensor Enable.Pressure Fallback Alert
Enable
Pressure Integral Dead Zone TB > Configure/Setup > Detailed Setup > Response Control > Pressure Tuning > Pressure Integral Dead Zone
Pressure Integral Gain TB > Configure/Setup > Detailed Setup > Response Control > Pressure Tuning > Pressure Integral Gain
Pressure Integral Limit Hi TB > Configure/Setup > Detailed Setup > Response Control > Pressure Tuning > Pressure Integral Limit Hi
Pressure Integral Limit Lo TB > Configure/Setup > Detailed Setup > Response Control > Pressure Tuning > Pressure Integral Limit Lo
Pressure MLFB Gain TB > Configure/Setup > Detailed Setup > Response Control > Pressure Tuning > Pressure MLFB Gain
Pressure Proportional Gain TB > Configure/Setup > Detailed Setup > Response Control > Pressure Tuning > Pressure Proportional Gain
Pressure Range Hi TB > Configure/Setup > Detailed Setup > Response Control > Travel Pressure Control > Pressure Range Hi
Pressure Range Lo TB > Configure/Setup > Detailed Setup > Response Control > Travel Pressure Control > Pressure Range Lo
Pressure Tuning Set TB > Configure/Setup > Detailed Setup > Response Control > Pressure Tuning > Pressure Tuning Set
Pressure Units TB > Configure/Setup > Detailed Setup > Instrument > Pressure Units
Processor Alert TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Elect Active.Processor Alert
Processor Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Elect Enable.Processor Alert Enable
Program Memory Alert TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Elect Active.Program Memory Alert
Program Memory Alert Enable
TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Elect Enable.Program Memory Alert
Enable
Program Memory Manual
Recovery
TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Shutdown Recovery.Program Memory
Manual Recovery
Program Memory Shutdown
TB > Configure/Setup > Detailed Setup > Alerts > Elect Alerts > Processor Impaired > Shutdown Trigger.Program Memory
Shutdown
Protection TB > Device Variables > Protection
−Continued−
