DVC6000f Series
March 2006
5-176
Table 5-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
PD Config PD_CONFIG Transducer 88.3 5-59
PD Detail 1 Active
PD_DETAIL1_ACTIVE Transducer 74.9 5-52
PD Detail 2 Active
PD_DETAIL2_ACTIVE Transducer 74.10 5-52
PD Detail 3 Active
PD_DETAIL3_ACTIVE Transducer 74.11 5-52
PD Detail 4 Active
PD_DETAIL4_ACTIVE Transducer 74.12 5-52
PD Detail 5 Active
PD_DETAIL5_ACTIVE Transducer 74.13 5-53
PD Detail 6 Active
PD_DETAIL6_ACTIVE Transducer 74.14 5-53
PD Event Active PD_EVENT_ACTIVE Transducer 74.8 5-51
PD Extra PD_EXTRA Transducer 88.4 5-59
PD Run PD_COMMAND Transducer 88.1 5-59
PD Status PD_STATUS Transducer 88.2 5-59
Performance PERF_DIAG Transducer 88 5-59
Performance Active PERF_ACTIVE Transducer 74.7 5-35, 5-51
Performance Enable PERF_ENABLE Transducer 75.7 5-35, 5-54
Port Diameter PORT_DIAMETER Transducer 84.3 5-37, 5-58
Port Type PORT_TYPE Transducer 84.4 5-37, 5-58
Press A Offset PRESS_A_OFFSET Transducer 46.4 5-46
Press A Scale PRESS_A_SCALE Transducer 46.3 5-46
Press B Offset PRESS_B_OFFSET Transducer 46.6 5-46
Press B Scale PRESS_B_SCALE Transducer 46.5 5-46
Press Cutoff Hi PRESS_CUTOFF_HI Transducer 47.1 5-28, 5-46
Press Cutoff Lo PRESS_CUTOFF_LO Transducer 47.2 5-29, 5-46
Press Integ DeadZ PRESS_INTEG_DEADZ Transducer 47.6 5-27, 5-46
Pres Integ Gain PRESS_INTEG_GAIN Transducer 47.4 5-27, 5-46
Press Integ Hi Lim PRESS_INTEG_HI_LIM Transducer 47.7 5-27, 5-46
Press Integ Lo Lim PRESS_INTEG_LO_LIM Transducer 47.8 5-27, 5-46
Press IP Bias PRESS_IP_BIAS Transducer 46.7 5-46
Press MLFB Bias PRESS_MLFB_BIAS Transducer 46.8 5-46
Press MLFB Gain PRESS_MLFB_GAIN Transducer 47.11 5-27, 5-46
Press Prop Gain PRESS_PROP_GAIN Transducer 47.3 5-27, 5-46
Press Range Hi PRESS_RANGE_HI Transducer 42.7 5-29, 5-44
Press Range Lo PRESS_RANGE_LO Transducer 42.8 5-29, 5-44
Press Rate Gain PRESS_RATE_GAIN Transducer 47.5 5-46
Press Tuning Set PRESS_TUNING_SET Transducer 42.11 5-26, 5-44
Pressure A Status
Pressure A
PRESSURE_A
STATUS
VALUE
Transducer
36
36.1
36.2
5-43, 7-6
Pressure B Status
Pressure B
PRESSURE_B
STATUS
VALUE
Transducer
37
37.1
37.2
5-43, 7-6
Pressure Diff Status
Press Diff
PRESSURE_DIFF
STATUS
VALUE
Transducer
38
38.1
38.2
5-43, 7-6
Pressure Units PRESSURE_UNITS Transducer 90 5-35, 5-60
Private Label Distributor DISTRIBUTOR Resource 42 5-17
Process Value PV
AI 7 5-126, 5-131
AO 7 5-67, 5-69, 5-69, 5-71, 5-72
PID 7 5-83, 5-84, 5-86
Protection PROTECTION Transducer 87 5-59
Process Value Discrete PV_D
DI 7 5-158, 5-160, 5-163
DO 7 5-147, 5-148, 5-149, 5-151
−Continued−
5
To Next Page
