Liebert iCOM Display Components and Functions
4
Figure 3 Status menu, large display, graphical view
Figure 4 Liebert iCOM default screen symbols
UNIT 1
11/11/2009 8 :31 MSG UNIT ON
11/11/2009 8 :30 MSG UNIT ON
11/11/2009 09 :18:07
ESC
for previous screen ? for help
UNIT ON
for system view
for next/previous unit
for menu
48
%
51.1
°F
ACT
72.9
°F
73.4°F 50% 50.9°F
100%
14%
0%
12/2011
0%
0%
0%
0%
SET
Evaporator
Fan Speed
Temperature
Setpoint
Humidity
Setpoint
Humidity
Sensor
Reading
Supply Air
Temperature
(optional)
Percent Hot Water
Heating
Percent Electric
Heating
Percent Dehumidifying
Percent Humidifying
System (or Unit) On/Off
Most Recent Alarms
(Date, Time, Unit,
Description)
System or
Unit # view
Temperature Sensor
Reading
Percent Cooling
Free-Cooling
Percentage
Next Maintenance
Date and Time
Supply Air
Setpoint
fan
cooling
maintenance
hot water
electric heat
dehumidification humidification
freecooling
