Service Menu Parameters
80
Figure 66 Set alarms parameters screen - Page 2
Customer Input 1, 2, 3 & 4—These parameters select the device and operation of the customer
inputs. Each event reflects a different alarm and possible action to the unit. Refer to table 7 for a
description of selectable options.
Customer Input 1, 2, 3 & 4 active when—These parameters select whether the input is a normally
closed or normally closed input.
WARNING ACTIVATES ALARM RELAY—This parameter sets the alarm relay (K3) to activate
when a warning occurs.
Water Alarm Shuts Unit Down—This parameter when set will turn the unit off if a water alarm
occurs.
Figure 67 Set alarms parameters screen - Page 3
Delay—The delay selection for each alarm
EN-DIS—The enable / disable selection for each alarm provides the ability to individually select the
alarms that will or will not activate when the alarm condition occurs.
SET ALARMS (page 2 of 7)
to change parameter
to confirm
to select parameter
for next/previous unit
then
PASSWORD (Actual Level 0) ????
Customer Input 1 Water Alarm
Customer Input 1 active when Closed
Customer Input 2 Water Alarm
Customer Input 2 active when Closed
Customer Input 3 C PMP Alarm
Customer Input 3 active when Closed
Customer Input 4 Water Alarm
Customer Input 4 active when Closed
WARNING ACTIVATES ALARM DELAY Yes
Water Alarm Shuts Unit Down No
S212
S213
S214
S215
S216
S217
S218
S219
S220
S221
S222
UNIT 01
SET ALARMS (page 3 of 7)
PASSWORD (Actual Level 0) ????
DELAY EN-DIS TYPE
MAIN FAN OVERLOAD 5 ENABLE ALM
LOSS OF AIRFLOW 30 ENABLE ALM
CLOGGED FILTERS 2 ENABLE WRN
HIGH ROOM TEMP 30 ENABLE WRN
LOW ROOM TEMP 30 ENABLE WRN
HIGH ROOM HUM 30 ENABLE WRN
LOW ROOM HUM 30 ENABLE WRN
HIGH TEMP SENSOR A 30 DISAB WRN
LOW TEMP SENSOR A 30 DISAB WRN
HIGH HUM SENSOR A 30 DISAB WRN
LOW HUM SENSOR A 30 DISAB WRN
S223
S224
S225
S226
S227
S228
S229
S230
S231
S232
S233
S234
S235
UNIT 01
h
to confirm
to select parameter
for next/previous unit
th
To Next Page
