Installing a Liebert iCOM Unit-to-Unit Network
51
Figure 33 Liebert vNSA with optional remote large display
Table 12 Ports available for connecting Liebert iCOM control devices
Model
Liebert
vNSA With
Remote
Large
Display
Total Number
of Ports
Number of Ports
Used to Connect
Remote Large
Display
Number of Ports
Used to
Interconnect
Switches
Number of Ports
Available to
Connect Liebert iCOM
Control Devices
Liebert vNSA8-Liebert
iCOM
Yes
81 - 7
Liebert vNSA16-
Liebert iCOM
16 1 2 13
Liebert vNSA8
No
8- - 8
Liebert vNSA16 16 - 2 14
3.298"
(84mm)
12"
(305mm)
14.25"
(362mm)
DPN001136
Rev. 0
