Installing a Liebert iCOM Unit-to-Unit Network
49
Figure 31 Wiring a small display for U2U network operation
Standard Small
Graphics Display
(Rear View)
Liebert iCOM
I/O Board
Straight-Through
Ethernet Cable
To / From Other
Networked Units
CAN
Cable
U2U Networking Switch
(Field-Supplied)
Not
Used
Cable 'C'
P64A Connection
Located Near
I/O Board
194273
