Emerson Liebert NXC - Page 17

16 User Manual 10H52188UM60 - Rev. 2 - 09/2012
Battery Liebert NXC
ARRANGE THE BATTERIES AND CONNECT THEM AS ILLUSTRATED IN Figure 2-1.
Figure 2-1 Internal Battery Cable Connection
BATTERY SHELF
BATTERY 8
BATTERY 7
BATTERY 6
BATTERY 5
BATTERY 4
BATTERY 3
BATTERY 2
BATTERY 1
XBS
TOP VIEW
FRONT
