Page #11 background imageLoading...
Page #11 background image
Micro Motion 7829 Viscomaster Dynamic Viscosity Meter 11
Ordering Information
Model Product description
7829 Viscosity meter
Code Material of wetted parts
F 316L Stainless steel, PFA laminated tines
Code Amplifier system
E Advanced: 4–20 mA output, ATEX Ex d IIC T4, < 200 °C
F Advanced: 4–20 mA output, CSA Class 1 Division 1, Groups C & D, < 200 °C
Code Amplifier enclosure
A Aluminium alloy [T4 (< 40 °C < Ta < +110 °C)]
Code Process connections
N 1.5" Cone seat compression fitting
Code Stem length
A 0 mm: no stem extension and with standard spigot
Code Default software configuration of 4–20 mA output 1
(1)
(1) 4–20 mA output 2 default setting is temperature.
H 0 to 25 cSt
J 0 to 50 cSt
Z ETO custom configuration
Code Calibration range
R 0.5 to 50 cP; no density calibration
Code Calibration type
AFree stream
B 2” schedule 40 boundary (200 cP limit)
E 3" schedule 80 boundary
(2)
(2) Compatible with DN80 XS pipework.
H 2-1/2” schedule 40 boundary
J 80 mm boundary
(3)
(3) With a minimum wall thickness of 0.24 in (6 mm).
Z ETO calibration type
Code Factory Set
B Reserved for future use
Code Traceability
A None
X Certificates of material traceability (per single order)
Typical model number: 7829FEANAHRABA
