3.2.2 Wire all available outputs using safety barriers
Micro Motion provides a safety barrier installation kit for wiring the meter in a hazardous
area. Contact your local sales representative or Micro Motion Customer Support at
flow.support@emerson.com for more information on ordering a barrier kit.
CAUTION!
• Meter installation and wiring should be performed by suitably trained personnel only in
accordance with the applicable code of practice.
• Refer to the hazardous area approvals documentation shipped with your meter. Safety
instructions are available on the Micro Motion Product Documentation DVD and
accessible on the Micro Motion website at www.micromotion.com.
The safety barrier kit provides barriers for connecting all of the available meter outputs.
Use the provided barriers with the designated output.
Output(s) Barrier
4–20 mA MTL7728P+
• 4–20 mA
• Time Period Signal (TPS)
• Discrete
MTL7728P+
Modbus/RS-485 MTL7761AC
Power MTL7728P+
Procedure
Wire the barriers to the appropriate output terminal and pins.
Wiring
26 Micro Motion
®
Gas Density Meters
