Emerson Micro Motion H Series - Page 8

Figure 1-1: Installation for self-draining applications
A
B
C
A. Process pipeline
B. Direction of normal process flow
C. Direction of drainage
Planning Installation Manual
January 2019 20002346
8 Micro Motion H-Series
