Dual core processor terminalsFigure 3-5:
A. Sensor 1
B. Sensor 2
Enhanced core processor terminalsFigure 3-6:
A
B
I
H
G
F
E
D
C
J
A. Brown
B. Violet
C. Yellow
D. Orange
E. Gray
F. Blue
G. White
H. Green
I. Red
J. Ground screw (black)
Wiring
Quick Start Guide 13
