124 Mentor MP User Guide
www.controltechniques.com Issue: 3
11.11 Menu 11: General drive set-up
* Modes 1 and 2 are not US (i.e. not saved when drive parameters are saved), mode 3 and 4 are US. Therefore this parameter can only be saved to
EEPROM if it has a value of 0, 3 or 4.
Parameter
Range(
Ú)Default(Ö)
Type
11.21 Parameter scaling 0 to 9.999 1.000 RW Uni US
11.22 Parameter displayed at power-up 0 to 00.90 00.40 RW Uni PT US
11.23 Serial address {Si02, 0.67} 0 to 247 1 RW Uni US
11.24 Serial mode 0 to 2 1 RW Txt US
11.25 Baud rate {Si01, 0.66} 0 to 9 6 RW Txt US
11.26 Minimum comms transmit delay 0 to 250ms 2 RW Uni US
11.29 Software version {di14, 0.49} 1.0 to 99.99
RO Uni NC PT
11.30 User security code 0 to 999 0 RW Uni NC PT PS
11.32 Current rating 0 to 10000.0A
RO Uni NC PT
11.33 Drive voltage rating 0 (480), 1 (575), 2 (690) RO Txt NC PT
11.34 Software sub-version 0 to 99 RO Uni NC PT
11.35 Number of modules 0 to 4 RW Uni PT US
11.36
SMARTCARD parameter data previously
loaded
0 to 999
0
RO Uni NC PT US
11.37 SMARTCARD data number 0 to 1003 RW Uni NC
11.38
SMARTCARD data type/
mode
0 to 18
RO Uni NC PT
11.39 SMARTCARDdata version 0 to 9999 0 RW Uni NC
11.40 SMARTCARD data checksum 0 to 65335
RO Uni NC PT
11.41 Status mode timeout 0 to 250s 240 RW Uni US
11.42 Parameter copying {SE09, 0.30} 0 to 4 0 RW Txt NC *
11.44 Security status {SE14, 0.35}
0 to 2 0RWTxtPTUS
11.45 Select motor 2 parameters OFF (0) or On (1) OFF (0) RW Bit US
11.46 Defaults previously loaded 0 to 2 Eur: or USA: 0 RO Txt PT US
11.47
Drive Onboard Application Lite Ladder
Program Enable
0 to 2 2 RW Uni US
11.48
Drive Onboard Application Lite Ladder
Program Status
-128 to +127
RO Bi NC PT
11.49
Drive Onboard Application Lite Ladder
Program Events
0 to 65535 RO Uni NC PT PS
11.50
Drive Onboard Application Lite Ladder
Program Maximum Scan Time
0 to 65335ms RO Uni NC PT
11.51
Drive Onboard Application Lite Ladder
Program First Run
OFF (0) or On (1) RO Bit NC PT
11.52 Drive serial number 0 to 999 999 999 RO Uni NC PT
11.53 Build location 0 to 255 RO Uni NC PT
11.55 Drive rating number 0 to 56 RO Uni NC PT
11.56 Power PCB software version 1.00 to 99.99 RO Uni NC PT
11.57 Serial programmable source Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
11.58 Serial scaling 0 to 1999 1000 RW Uni US
11.59
Mentor II Parameter Emulator Module
Control
0 to 3 0 RW Uni US
11.60 Application parameters
16000 to -16000
RW Uni NC
11.61 Application parameters RW Uni NC
11.62 Full power discharge time 0 to 25.0s
0.0
RW Uni US
11.63 Full power discharge period 0 to 1500.0s RW Uni US
11.64 External discharge resistance 0 to 9999Ω 0RWUniUS
11.65 External resistor temperature 0 to 100%
RO NC PT
11.66 Suppressor voltage 0 to 2000V
RO NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
