Connecting The Speakers
NOTE: Always connect the speakers before switching the power ‘On’,
and never operate the system without the speakers properly connected.
Make sure:
The left speaker is connected the left-pair (L) terminals.
The right speaker is connected the right-pair (R) terminals.
The speaker cables and the speaker terminals are color-coded.
Connect the Red wires to the Red terminals.
Connect the Black wires to the Black terminals.
If the wires are connected incorrectly the sound will be “muddy” or distorted.
To make the connection, completely depress the plastic levers to open the terminals,
insert the bare end of the speaker wire into the terminal openings, and release the
plastic levers to lock the wires in place.
+
(Red Color)
(Black Color)
