PACSystems™ RX3i and RSTi-EP CPU Reference Manual Section 6
GFK-2222AK October 2019
Serial I/O, SNP & RTU Protocols 154
6.2.12.3 Sample Autodial Command Block
This COMMREQ command block dials the number 234-5678 using a Hayes-compatible
modem.
Word
Definition
Values
1
0009h
CUSTOM data block length (includes command string)
2
0000h
NOWAIT mode
3
0008h
Status word memory type (%R)
4
0000h
Status word address minus 1 (Register 1)
5
0000h
not used
6
0000h
not used
7
04400 (1130h)
Autodial command number
8
00030 (001Eh)
Modem response timeout (30 seconds)
9
0012 (000Ch)
Number of bytes in command string
10
5441h
A (41h), T (54h)
11
5444h
D (44h), T (54h)
12
3332h
Phone number: 2 (32h), 3 (33h)
13
3534h
4 (34h), 5 (35h)
14
3736h
6 (36h), 7 (37h)
15
0D38h
8 (38h) <CR> (0Dh)
6.2.13 Write Bytes Function (4401)
This operation can be used to transmit one or more characters to the remote device
through the specified serial port. The character(s) to be transmitted must be in a word
reference memory. They should not be changed until the operation is complete.
Up to 250 characters can be transmitted with a single invocation of this operation. The
status of the operation is not complete until all the characters have been transmitted or
until a timeout occurs (for example, if hardware flow control is being used and the remote
device never enables the transmission).
