PACSystems™ RX3i and RSTi-EP CPU Reference Manual Section 2
GFK-2222AK October 2019
CPU Features & Specifications 36
2.3.1 CPE100/CPE115
2.3.1.1 Introduction
The EPSCPE100 and EPSCPE115 are the first standalone CPUs in the RSTi-EP family. Each is
supported by two mounting options:
1. As shipped, it mounts onto a DIN rail using a DIN-rail adaptor plate.
2. Alternately, it mounts directly in a cabinet, using a panel-mount adaptor plate
ICMFAACC001-AA.
The mounting instructions and power requirements are documented in the Quick
Start Guide, GFK-3012, and are not replicated here.
The physical features of the CPE100/CPE115 are shown in Figure 2.
Figure 2: CPE100, Front, Top, and Bottom Views and Features
Top View
Bottom View
