PACSystems™ RX3i and RSTi-EP CPU Reference Manual Section 6
GFK-2222AK October 2019
Serial I/O, SNP & RTU Protocols 182
▪
Response Data
(Minor Type)
CPU Model
77
02 hex
IC698CPE010
04 hex
IC698CPE020
05 hex
IC698CRE020
06 hex
IC698CPE030
08 hex
IC698CPE040
0A hex
IC695CPE302
IC695CPE305
IC695CPU310
0C hex
IC695NIU001
10 hex
IC695CPU320
11 hex
IC695CRU320
12 hex
IC695CPE302
IC695CPE305
18 hex
IC695CPU315
6.3.3.12 Message (22): Mask Write 4x Memory
Modifies the contents of a specified 4x register using a combination of an AND mask, an
OR mask, and the register's current contents. The function can be used to set or clear
individual bits in the register. Broadcast is not supported.
6.3.3.12.1 Query:
The query specifies the 4x reference to be written, the data to be used as the AND mask,
and the data to be used as the OR mask.
The function's algorithm is:
Result = (Current Contents AND And_Mask) OR (Or_Mask AND And_Mask)
For example:
Hex
Binary
Current Contents
12
0001
0010
And_Mask
F2
1111
0010
Or_Mask
25
0010
0101
And_Mask
0D
0000
1101
Result
17
0001
0111
77
Does not apply to CPE330, which has no serial ports.
