PACSystems™ RX3i and RSTi-EP CPU Reference Manual Section 6

GFK-2222AK October 2019

Serial I/O, SNP & RTU Protocols 185

6.3.3.13.2 Response:

The normal response contains the data from the group of registers that were read. The

Byte Count field specifies the quantity of bytes to follow in the Read Data field.

Here is an example of a response to the query:

Field Name

Example (Hex)

Slave Address

Function

Byte Count

Read Data 1 Hi

Read Data 1 Lo

Read Data 2 Hi

Read Data 2 Lo

Read Data 3 Hi

Read Data 3 Lo

Read Data 4 Hi

Read Data 4 Lo

Read Data 5 Hi

Read Data 5 Lo

Read Data 6 Hi

Read Data 6 Lo

Error Check (LRC or CRC)
