PROFINET Controller (PNC001) and PROFINET I/O Sweep Impact
The PLC CPU sweep impact for a PROFINET IO network is a function of the number of
PNCs, the number of PROFINET devices, and the number of each PROFINET device’s IO
modules. The table below shows the measured sweep impact of the RX3i PROFINET
Controller, supported VersaMax PROFINET devices, and I/O modules.
Sweep Impact Item
CPU315/CPU320
(µs)
CPE302/CPE305/CPE310
(µs)
CPE330
w/PNC001
(µs)
CPE330
w/Embedded
PNC
(µs)
CPE400/CPL410
w/Embedded
PNC
(µs)
RX3i PROFINET
Controller (PNC)
50
48
43
16
12
RX3i Devices
PROFINET Scanner
(PNS) IC695PNS001
46
73
42
10
24
ALG442 Mixed
Analog
54
76
38
25
20
ALG220 Analog Input
27
45
29
14
10
ALG390 Analog
Output
24
33
12
13
10
MDL645 Discrete
Input
23
36
18
15
10
MDL740 Discrete
Output
22
31
9
14
9
VersaMax Devices
PROFINET Scanner
(PNS), IC200PNS001
40
80
38
15
24
Discrete Input
Module (8/16/32 pt.)
23
40
23
10
10
Discrete Output
Module (8/16/32 pt.)
18
45
24
13
12
Analog Input Module
(15 channel)
59
96
67
10
11
Analog Output
Module (12 channel)
21
45
27
12
14
CMM020
(64AI/64AQ)
204
263
188
18
18
To calculate the total expected PLC sweep impact for a PROFINET I/O network, add the
individual sweep impact times for each PROFINET Controller, PROFINET Device, and
PROFINET Device I/O module, using the times provided above.
For example, for a PROFINET I/O network that consists of one PNC and one VersaMax
PROFINET Scanner, which has both an 8-point input and an 8-point output module:
Expected PLC Sweep Impact
= 50 (PNC) + 40 (PNS) + 23 (8pt. Input) + 18 (8pt. Output)
=131 µs.
