ROC800-Series Instruction Manual
1-4 General Information Revised July-2017
Module
ROC809 Series 1 CPU
ROC809 Series 2 CPU
Module Color
RS-485
1st three slots
1st three slots
Grey
RS-232
1st three slots
1st three slots
Grey
Dial-up Modem
1st three slots
1st three slots
Grey
MVS
3
1st three slots
1st three slots
Grey
MVS I/O
1st three slots
Any
Black
DI
Any
Any
Grey
HART
Any
Any
Grey
HART-2
None
Any
4
Black
DO
Any
Any
Grey
DOR
Any
Any
Grey
RTD
Any
Any
Grey
TC
Any
None
Grey
TC2
None
Any
5
Black
PI
Any
Any
Grey
IEC 62591
None
Any
Black
NRM
None
1st three slots
Black
AC I/O
Any
Any
Grey
APP485
Any
Any
Black
1
With firmware version 2.13 or greater
2
With firmware version 2.10 or greater
3
The ROC809 supports a maximum of two MVS modules
4
With firmware version 3.10 or greater
5
With firmware version 3.20 or greater
Table 1-2. ROC827 Module Placement (Series 1 CPU vs. Series 2 CPU)
Module
ROC827 Series 1 CPU
ROC827 Series 2 CPU
Module Color
AI-12
Any
Any
Grey
AI-16
Any
Any
Black
AO
Any
Any
Grey
APM
1st three slots
2
Any
Grey
RS-485
1st three slots
1st three slots
Grey
RS-232
1st three slots
1st three slots
Grey
Dial-up Modem
1st three slots
1st three slots
Grey
MVS
3
1st three slots
1st three slots
Grey
MVS I/O
1st three slots
Any
Black
DI
Any
Any
Grey
HART
1st three slots
Any
Black
HART-2
None
Any
Black
DO
Any
Any
4
Grey
DOR
Any
Any
Grey
RTD
Any
Any
Grey
TC
Any
None
Grey
TC2
None
Any
5
Black
PI
Any
Any
Grey
IEC 62591
None
Any
Black
NRM
None
1st three slots
Black
AC I/O
1st three slots
Any
Grey
APP485
Any
Any
Black
1
With firmware version 2.13 or greater
