Emerson ROC809 - Micro Motion RFT9739 & 2400 S Transmitters to PI Module

ROC800-Series Instruction Manual
Revised July-2017 Wiring Diagrams B-3
B.3 Micro Motion RFT9739 & 2400S Transmitters to PI Module
12KHz PI FILTER &
LEVEL DETECTION
12KHz PI FILTER &
LEVEL DETECTION
DOC0740A
14
15
16
17
14
15
16
17
MICRO MOTION
RFT9739
TRANSMITTER
MICRO MOTION
RFT9739
TRANSMITTER
12KHz PI FILTER &
LEVEL DETECTION
12KHz PI FILTER &
LEVEL DETECTION
DOC0741A
3
4
1
2
3
4
1
2
MICRO MOTION
2400S
TRANSMITTER
MICRO MOTION
2400S
TRANSMITTER
