60529-05, CAN/CSA C22.2 No. 60079-0:11, CAN/CSA
C22.2 No. 60079-11:14, CAN/CSA Std. No. 61010-1-12
Markings:
CL I/II/III, DIV 1, GP B, C, D, E, F, G
See I6 description for Intrinsic Safety and Division 2
markings.
5.6 Europe
5.6.1 E1 ATEX Flameproof
Certificate:
DEKRA 19ATEX0076 X
Standards:
EN IEC 60079-0: 2018, EN 60079-1: 2014
Markings:
II 2 G Ex db IIC T6…T1 Gb, T6(–60 °C ≤ T
a
≤ +70 °C),
T5…T1(–60 °C ≤ T
a
≤ +80 °C)
Special Conditions for Safe Use (X):
1. Flameproof joints are not intended for repair.
2. Non-Standard Paint options may cause risk from electrostatic
discharge. Avoid installations that cause electrostatic build-up
on painted surfaces, and only clean the painted surfaces with a
damp cloth. If paint is ordered through a special option code,
contact the manufacturer for more information.
Additional Specific Conditions of Use (X) when “XA” designation is
ordered:
Guard DIN Style sensors against impacts greater than 4 J.
Process temperature
range at Sensor
Connection (°C)
(1)
Ambient temperature
range (°C)
Temperature class
-60 °C to +70 °C -60 °C to +70 °C T6
-60 °C to +80 °C -60 °C to +80 °C T5…T1
(1) Sensor Connection is where the sensor threads into the transmitter or
junction box housing.
5.6.2 I1 ATEX Intrinsic Safety
Certificate:
[Headmount HART
®
]: Baseefa12ATEX0101X
[Headmount Fieldbus/PROFIBUS
®
]:
Baseefa03ATEX0499X
[Railmount HART]: BAS00ATEX1033X
April2023 Quick Start Guide
Quick Start Guide 27
