Figure 5-2: Proper conduit installation
C
B
D
A A
A. Conduit line
5.4 Wire the flowmeter
Use the following figures and steps to wire the flowmeter:
About this task
Figure 5-3: 4–20 mA wiring
A
+
-
R
L
≥ 250 Ω
A. Power supply
October 2018 Quick Start Guide
Quick Start Guide 17
